Electrical Steel B30P105 mainly low-carbon steel, requires a good cold bending and welding properties, as well as some of the press performance.
Electrical Steel B30P105 steel Mechanical Properties
|
Grade |
Nominal thickness（mm） |
tensile strength L（N/mm2） |
Yield Strength L（N/mm2） |
Elongation L（%） |
Hardness HV1 |
Bending frequency (times) |
Stacking factor（%） |
|
B30P105 |
0.30 |
350 |
310 |
11 |
195 |
17 |
98.0 |
NOTE:.
a detector according to GB / t228-2002, GB / T 19289-2003
b. above are typical values only for reference does not guarantee
c. L direction refers to the rolling direction
Electrical Steel B30P105 steel Electromagnetic induction standard
|
Grade |
Nominal thickness（mm） |
Theoretical density（kg/dm3） |
Maximum core loss P17/50 |
minimum magnetic induction B8 |
|
0.30 |
7.65 |
1.05 |
1.88 |
