Electrical Steel B50AR300 steel

Electrical Steel B50AR300 steel thickness of 0.5mm, the iron loss P15 / 50 W / kg not more than 3.0, the magnetic flux density peak B50 T is not less than 172% stacking factor of not less than: 96

Thickness: 0.1,0.2,0.35 mm 0.5mm
Width: 50- 1250 mm
Weight: 4-8MT,1-4MT

Electrical Steel B50AR300 electromagnetic performance standards :


Grade

Nominal thickness（mm）

Theoretical density（kg/dm3）

Maximum core loss P17/50
(W/kg)

The minimum magnetic induction B8
（T）

B50AR300

0.50

7.75

3.00

1.72
