B50AH470

B50AH470 is a soft magnetic alloy ferrosilicon very low carbon content, usually silicon content of 0.5 to 4.5%. Added silicon can improve iron resistivity and maximum permeability and lower coercive force, core loss (iron loss) and magnetic aging.

B50AH470 steel surface is smooth, flat and uniform thickness can be improved fill factor core, adhesion and weldability surface of the insulating film is good, and can improve the corrosion resistance punching

B50AH470 steel Mechanical Properties

Grade

Nominal thickness(mm)

tensile strength L(N/mm2)

Yield Strength L(N/mm2)

Elongation L(%)

Hardness HV1

Bending frequency (times)

Stacking factor(%)

B50AH470

0.50

7.75

399

243

36

143

≥15

B50AH470 steel sheet/plate Electromagnetic induction standard

Grade

Nominal thickness(mm)

Theoretical density(kg/dm3)

Maximum core loss P17/50
(W/kg)

minimum magnetic induction B8
(T)

B50AH470

0.50

7.75

4.70

1.72

Shanghai Royal Industry Will return you with high-quality products and complete after-sale service with the lowest price. we committed to exceed customer's expectation on the basis of quality, price, and delivery. We sincerely hope to establish long-term cooperation relationship with you on the basis of mutual benefit, reciprocity and common development. As B50AH470 Mechanical and B50AH470 suppliers, we can supply B50AH470 Chemical, B50AH470 Mechanical and B50AH470 standard for you ,please contact us :info@sg295steel.com
